PTC elements for uniform heating without any power variation

– With self-regulating properties for air & water heating

PTC element 12 mm

This element automatically adjusts its power consumption until it reaches a pre-set temperature (Curie temperature). Thanks to its self-regulating properties, the same element can be used both for air- and water heating without any risk of overheating.

We have a standard range of PTC 12 mm as well as custom made products.



Technical data

Material (tube)

AISI 316L/EN 1.4404, AISI 304/EN 1.4301

Dimension

Ø 12 mm, length 50-300 mm

Connection

Connection one side, G3/8'', G 1/2'', G1''

Voltage

110-240 V

Surface load

3,7 W/cm² at 0°C
0,3 W/cm² in still air

Curie set points

50-180°C

Optional

Wiring, vulcanized connection

Safety

The elements meet requirements per EN 60335-1

Examples of applications

  • Defrosting
  • Towel dryers
  • Radiators
  • Evaporation of condensed water



Benefits

  • No overheating protection, regulation required
  • Quickly reaches working temperature
  • Can be installed in any direction
  • Energy saving depending on product design
