Micanite elements
Micanite elements are typically used for contact heating of tools and for indirect heating of liquids in vessels.
Micanite is an excellent insulation material based on mica. The micanite sheets can be cut, punched or shaped to fit in tools, etc.
Micanite elements enclosed in flat or round metal sheeting are called band heaters.
Technical data
Material | Micanite, based on glimmer |
Connections | Cable, tab terminals, screw and nut |
Surface load | 3-4 W/cm² (at max. 350°C) |
Operating temp. | Max. 700°C (at max. 4 W/cm²) |
Voltage | Max. 480V |
Safety | The elements meet requirements per EN 60335-1 |
Example applications
- Protection against cold
- Tool heating
- Drying equipment
- Toasters
- Heating plates
-
